Leben CS-1000P lempinis galios stiprintuvas

High power output tube KT120(Super KT88)

100W/ch(1KHz) at Pentode circuit (70W/ch at Triode).

Pentode/Triode selector switch

Bias adjustment with a Cathode-direct meter

Several type of output tubes are applicable by adjusting the cathodal electric current.

Newly developed Orient-core output transformer

A minimum loss and a Superior high-frequency response.

Flat and wide Frequency Response

A wide frequency response from 10Hz to 150KHz(-0dB) caters for digital audio formats such as SACD/HDCD.

High rigidity solid aluminum insulators

OTHER FEATURES

Super-high sensitivity bias meter made by a long-established manufacturer.

High-grade Metal glaze resistorals of below 1% error margin.

High-grade 41-steps Detent Volume of ALPS.

Specifikacijos

Techninės savybės:

• Panaudotos lempos:

 KT120 x 4

 6922/6DJ8(ECC88) x 2

 6CG7/6FQ7 x 2

• Stiprintuvo galia: 100W x 2 at 1KHz.

• Dažnių juosta: 10Hz - 150KHz (-2 dB)

• Įėjimo jautrumas: 0.4V at 50W

• Įėjimo varža: 100K Ohms

• Palaikoma garso kolonėlių varža: 4/6/8 Ohms (pasirenkama)

Įvestys/išvestys:

• 1x Analoginiai stereo įėjimai

Matmenys ir svoris:

• Matmenys: 455 (W) X 200 (H) X 335 (D) mm

• Svoris: 23,5 kg.
