PSB C-LCR įmontuojama kolonėlė

C-LCR – Angled In-Ceiling Speaker

Superb Home-Theatre Sound with Zero Footprint

The CustomSound C-LCR is the ideal speaker for many installations as part of an invisible surround-sound system. Capable of pumping out clear, natural vocals and instruments with no harshness, this in-ceiling speaker sounds like a high-end stand-mount monitor. The C-LCR’s angled baffle directs sound down and toward your listening position, making movie soundtracks feel like they’re coming from the action on the screen, and not several feet above it.

Two 5¼” (133mm) polypropylene cone woofers

1″ (25mm) titanium dome, ferrofluid-cooled tweeter

Stand Out by Blending In

The cabinet of the C-LCR is 7¾” (196mm) deep, taking advantage of the extra ceiling space in most homes. This allows for an optimal internal volume of 0.36 cubic feet (10.24L). The provided white magnetic grilles attach to the front frame of the speaker, seamlessly covering the entire unit to conceal it from view. The speaker cabinet features cable tracks for clean and efficient wire management. As with all PSB products, these are very musical sounding speakers that blend effortlessly into any space.

Two 5¼” (133mm) polypropylene cone woofers

1″ (25mm) titanium dome, ferrofluid-cooled tweeter

Frequency response: 65-23,000Hz (±3dB)

Includes magnetic “frameless” and paintable grille with fabric scrim

Frequency Response

On Axis @ 0° ±3dB 65-23,000Hz

On Axis @ 0° ±1 1/2dB 70-20,000Hz

LF Cutoff -10dB 50Hz

Sensitivity

Anechoic Chamber 88dB

Listening Room 90dB

Impedance

Nominal 6 Ohms

Minimum 4 Ohms

Input Power

Recommended 20 - 150 Watts

Program 150 Watts

Acoustic Design

Tweeter (Nominal) 1” (25mm) Titanium Dome with Ferrofluid

Woofer (Nominal) 2 x 5 1/4” (133mm) Clay/Ceramic reinforced Polypropylene Cone

Rubber Surround

Crossover 1750Hz, LR4

Internal Volume 0.36 cu ft (10.24L)

Design Type Sealed

Dimensions / Weights / Finish

Size (W x H x D) Cutout Dimensions - 13 3/16 x 13 3/16” * (335 x 335mm)

Mounting Depth - 7 3/4” (196mm) *

Grille Dimensions - 14 3/4 x 14 3/4 x 3/8” * (373 x 373 x 7mm)

Weight Net - 17.6lb (8.8kg)/each

Shipping - 24lb (10.9kg)/each

Finish White
