Silent Angel Munich MU tinklo grotuvas

Designed for Ultimate Sound Quality.

Munich MU is High-End’s premier network streamer, advancing the formidable capabilities of the iconic M1. The development of a sophisticated, double-layer chassis design inspired by our State-of-the-Art Bonn NX and Genesis GX combined with meticulous fine-tuning and relentless testing, complemented by specialized system software, every effort has been devoted to creating an unmatched digital audio experience.

Enhanced Interface For High-Fidelity Digital Music.

Upgrading The Finest Systems: Featuring both XLR balanced and RCA (single-ended) outputs, coupled with an integrated ESS SABRE DAC, Munich MU delivers reference-grade analog sonics. Simply connect MU to your amplifier or active speakers and instantly elevate your audio system to a true high-end HiFi audio experience.

Versatile Audio Source with Expandable DAC connectivity via USB Audio port for rich high-definition digital output, meeting diverse connection needs. Enhanced with advanced lossless audio transmission for unparalleled sound quality.

Double-Layer Chassis with Integrated Manufacturing Process.

Munich MU offers superior structural integrity compared to welded sheet metal enclosures, providing enhanced resonance damping and better electromagnetic interference isolation, thereby ensuring pristine audio quality.

The Perfect Digital Circuit, Engineered to Minimize Noise in Digital Signals.

Utilizing Unique Shielding Technology to Isolate Interference Between Digital and Analog Circuits.

High-Precision Clock Adjustment with Independent Circuitry.

High-Precision TCXO Clock Fine-Tuned Surrounding Power Circuitry to Femtosecond Levels.

External 10MHz Clock Input.

Utilizing High-Precision TCXO Clocks and optimizing the clock peripheral circuits, MU minimizes network latency and jitter to vanishingly low levels. Equipped with an internal/external clock selector switch, MU enables seamless switching between internal and external clock sources.

Available Color Black, Silver

Ethernet 1 GbE RJ45 x 1

Management System: VitOS Orbiter (for iOS, Android)

LED Indicator:

Red, green, and blue lights flash in sequence > System booting

Blue light remains steady > Startup process completed

Blue light stays steady > Standby mode

Red light blinks > Mute mode

Green light blinks > PCM output format

Blue light blinks > DSD output format

Audio Format AAC, M4A, MP3, OGG, FLAC, WAV, ALAC, DSD (DSF, DFF), WAV64, AIFF, CUE Files, WMA, APE

Digital Outputs AES/EBU port x 1

I2S port x 1*

Coxial port x 1

- Supports up to PCM 384KHz and DSD 5.6M (DSD128)

* I2S output signal is not compatible with Holo Audio's DAC

USB Audio USB Audio port x 1

- Supports up to PCM 768KHz and DSD 11.2M (DSD256)

Analog Output Balanced XLR Outputs, Unbalanced RCA (L+R) Outputs

USB external storage USB 3.0 x 2

USB 2.0 x 1

External Clock Input Port: 10MHz x 1

CPU:Dual-core Cortex-72, frequency 1.8GHz +

Quad-core Cortex-A53, frequency 1.4GHz

RAM Low-Noise 4GB

Firmware and System High-Speed 32GB

SSD Storage: M.2 NVMe SSD (2280) Reserved, Up to 4TB, This product does not include a hard drive.

Chassis Material: Aluminum alloy material sandblasted anodized appearance, Double-layer casing isolation design.

Dimensions 360(W)*73(H)*220(D)mm

Weight 4.65KG

Package:

Player, Power cord, Network cable, Quick install guide, Warranty card.
