Chord Hugo2 mobilus keitiklis (DAC) su ausinių stiprintuvu

Geriausias DAC'as What HiFi 2018 metų apdovanojimuose virš £1200 kategorijoje.

Chord Custom FPGA DAC

49,152 Taps

7 hour Battery Life

768kHz Micro USB Input

384kHz Coax Jack Input

192kHz Optical Input

Bluetooth Apt X Input

1x ¼” Headphone Output

1x 3.5mm Headphone Output

Unbalanced RCA Outputs

Supports up to 768kHz

DSD512 (8x) Native

Native DSD Support

4x Playback Filters

3x Crossfeed Function

Supports up to 800Ω

IR Remote Control Included

CNC Aluminium Chassis

HUGO 2 – SPECIFICATIONS:

Materials: Clamshell precision machined aluminium casing with polycarbonate  buttons, acrylic signal window, and glass viewing portal. Available in a choice of two colours – natural silver, and satin black

Battery: 2x Rechargeable custom Enix Energies 3.7v 9.6Wh Li-ion (lithium-ion (2600mAh) batteries*

Tap length filter: 49,152 – 10 element Pulse Array design

Play time: In excess of seven (7) hours

Charging: Nominal four (4) hours via Micro USB at 1.8amps (fast charge) – Nominal eight (8) hours at 1amp (slow charge)

Connectivity (input): Micro USB (White): 44.1kHz – 768kHz – 16bit – 32bit

Coax via 3.5mm Jack (Red): 44.1kHz – 768kHz – 16bit – 32bit

Optical (Green): 44.1kHz – 192kHz – 16bit – 24bit

Connectivity (input wireless): Bluetooth (Apt X) (Blue): 44.1kHz – 48kHz – 16bit

Connectivity (output): 1x ¼” jack headphone output

1x 3.5mm jack headphone output

1x stereo (L & R) RCA output

PCM support: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 358.8kHz, 384kHz, 717.6kHz, and 768kHz.

DSD support: Native playback supported. DSD64 (Single) to DSD512 (Octa-DSD)

Volume control: Digital, activated in 1dB increments. Last known state saved upon shutdown, with exception of line-level mode

Line-level mode: Activated via dual press of middle ‘Source’ and ‘Crossfeed’ buttons. Line level = 3v via all outputs. Reset by power cycle

Power saving mode: Auto-shutdown after ten minutes of input inactivity

Driver support: Driverless with Mac OS X and Linux, driver required for Windows OS

Technical specifications:

Chipset: Chord Electronics custom coded Xilinx Artix 7 (XC7A15T) FPGA

Tap-length: 49,152

Pulse array: 10 element pulse array design

Frequency response: 20Hz – 20kHz +/- 0.2dB

Output stage: Class A

Output impedance: 0.025Ω

THD: <0.0001% 1kHz 3v RMS 300Ω

THD and noise at 3v RMS: 120dB at 1kHz 300ohms ‘A’ wighted (reference 5.3v)

Noise 2.6 uV ‘A’ weighted: No measurable noise floor modulation

Signal to noise ratio: 126dB ‘A’ Weighted

Channel separation: 135dB at 1kHz 300Ω

Power output @ 1kHz 1% THD: 94mW 300Ω

740mW 32Ω

1050mW 8Ω

Weight: 450g

Dimensions: 130mm (L) x 100mm (W) x 21mm (H)

Boxed Dimensions: 220mm (L) x 122mm (W) x 85mm (H)
